iceFUN

iceFUN iCE40-HX8K FPGA

3 High current 12/24v RGB drivers, 1A per channel.
4 10-bit Analogue input channels via onboard PIC.
32 red LEDs, on-board LED matrix (4*8)
4 push button inputs with pull-up resistors
1 piezo sounder for sounds or tunes.
45 FPGA I/O pins available (3.3 volt).

iCE40 HX FPGA:
7680 Logic cells
128k bits embedded RAM (32 * 4k bit blocks)
2 PLL's

An on-board PIC16LF1459 takes care of USB programming, FPGA reset and start-up and also provides 4 * 10-bit analogue channels. These are available via a serial port to the FPGA. The PIC also generates a 12MHz clock to the FPGA which may be multiplied in a PLL as required. Power is from USB or a nominal 5 volts (3.5v to absolute max. 6v)
